Icom ID-51A Advanced Instructions

9
D-STAR OPERATION <ADVANCED>
9-29
Repeater list programming (Continued) ■
Duplex direction setting9.
• This item appears only when “YES” is selected in
[7. Access repeater setting].
• “DUP–” is automatically set when the access re-
peater frequency is programmed in [8. Access re-
peater frequency programming].
• If necessary, you can change the duplex direction.
#6 Push D-pad() to select “DUP,” and then push D-
pad(Ent).
D-pad
(�)
(Ent)
#7 Push D-pad() to select the duplex direction.
• OFF : Turn the duplex function OFF.
For a simplex operation, this item MUST be set to
“OFF.”
• DUP– : The transmit frequency shifts down from the re-
ceive frequency by the offset amount.
• DUP+ : The transmit frequency shifts up from the receive
frequency by the offset amount.
#8 After setting, push D-pad(Ent).
Frequency offset programming10.
• This item appears only when “YES” is selected in
[7. Access repeater setting].
• The offset value* is automatically set when the ac-
cess repeater frequency is programmed in [8. Ac-
cess repeater frequency programming].
*The default value differs, depending on the version.
• If necessary, you can change the frequency offset.
#9 Push D-pad() to select “OFFSET FREQ,” and then
push D-pad(Ent) to enter the frequency offset edit
mode.
• A cursor appears and blinks.
$0 Rotate [DIAL] to input the frequency offset.
$1 Push to move the cursor backward, or push to
move the cursor forward.
$2 Repeat steps $0 and $1 to enter the frequency off-
set.
$3 After entering, push D-pad(Ent).
☞ Continued on the next page.
Previous view

Icom ID-51A Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Antenna Connector	SMA
GPS Receiver	Yes
Waterproof	IPX7
Modes	FM, DV
Weight	255 g
Memory Channels	1304 channels
Output Power	5W (High), 2.5W (Middle), 0.5W (Low)
