Icom ID-51A Advanced Instructions

16
MENU SCREEN
16-8
Menu items and Default settings (Continued) ■
NOTE: The default settings shown below are for the USA version.
The default settings may differ, depending on your transceiver version.
GPS Auto TX OFF, 5sec, 10sec, 30sec, 1min, 3min, 5min, 10min or 30min
Enters an unproto address, or keep the
default.
Selects whether to transmit the course
and speed data or not.
Selects a format to transmit the current
UTC time as a time stamp.
Turns the altitude transmit option ON or
OFF.
Selects a desired GPS-A Symbol to
transmit.
Selects the APRS
®
call sign SSID.
Selects a time option for the GPS auto-
matic transmission function.
Enters a comment to transmit.
Data Extension
Time Stamp
Altitude
GPS-A Symbol
SSID
Comment
Unproto Address
OFF or Course/Speed
OFF, DHM or HMS
OFF or ON
1:Person, 2:Bicycle, 3:Car or 4:House QTH (VHF)
- - -, (-0), -1~-15 or -A~-Z
API51,DSTAR*
GPS (Continued)
In this item, set the GPS options.
DESCRIPTIONS
RANGE OR VALUE (Default is shown in bold)
OFF
GPS(DV-G)
GPS TX Mode
GPS Sentence
GPS Message
RMC, GGA, GLL, VTG, GSA or GSV
Select GPS or DPS-A as the data mode
when transmitting GPS data, or select OFF.
Transmits position data in selected GPS
sentences.
Enter a GPS message to be transmitted.
Turns OFF the GPS TX function.
GPS-A(DV-A)
Previous view

Icom ID-51A Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Antenna Connector	SMA
GPS Receiver	Yes
Waterproof	IPX7
Modes	FM, DV
Weight	255 g
Memory Channels	1304 channels
Output Power	5W (High), 2.5W (Middle), 0.5W (Low)
