IDEC SmartRelay functions
IDEC SmartRelay Manual 117
Valid ranges of the timebase, if T = parameter
The display in programming mode (example):
Valid ranges of the timebase, if T = Actual value of an already pro-
grammed function
The display in programming mode (example):
If the referenced block (B6, in the example) returns a value
that lies out of the valid range, the value is rounded up or
down to the next valid value.
Timebase max. value min. resolution Accuracy
s (seconds) 99:99 10 ms +
10 ms
m (minutes) 99:59 1s +
1 s
h (hours) 99:59 1 min +
1 min
Timebase max. value min. resolution Accuracy
ms 99990 Number of ms +
10 ms
s 5999 Number of s +
1 s
m 5999 Number of min +
1 min
