Getting started with IDEC SmartRelay
IDEC SmartRelay Manual 9
Expansion modules
The following expansion modules can be connected to the
IDEC SmartRelay:
Certification and approvals
IDEC SmartRelay is certified to cULus and FM.
• cULus Haz. Loc.
Underwriters Laboratories Inc. (UL) to
- UL 508 (Industrial Control Equipment)
- CSA C22.2 No. 142 (Process Control Equipment)
- UL 1604 (Hazardous Location)
- CSA-213 (Hazardous Location)
APPROVED for use in
Class I, Division 2, Group A, B, C, D Tx
Class I, Zone 2, Group IIC Tx
• FM Approval
Factory Mutual Research (FM) to
Approval Standard Class Number 3611, 3600, 3810
APPROVED for use in
Class I, Division 2, Group A, B, C, D Tx
Class I, Zone 2, Group IIC Tx
Symbol Description Supply Voltage Inputs Outputs
FL1B-M08B2R2 12/24 V DC 4 digital 4 relays (5A)
FL1B-M08B1S2 24 V DC 4 digital 4 Transistor
24 V / 0.3 A
FL1B-M08D2R2
(1)
(1): Digital inputs can be operated either with P or with N action.
24 V AC/DC 4 digital 4 relays (5A)
FL1B-M08C2R2 100...240 V AC/DC
4 digital
(2)
(2): Different phases are not allowed within the inputs.
4 relays (5A)
FL1B-J2B2 12/24 V DC 2 analog
0 ... 10 V or
0 ... 20 mA
(3)
(3): 0 ... 10 V, 0 ... 20 mA can be connected optionally.
none
