IDEC SmartRelay functions
186
IDEC SmartRelay Manual
Changing parameters in the active message text
You can allow editing of parameter and process variables in
an active message text by entering a “+” in the first line. To
prevent changes, enter a “-” sign.
When the message text is active, press ESC to select the ed-
iting mode.
Note
You must keep the ESC key pressed at least for one second.
Press and to select the relevant line (you can only se-
lect lines that contain parameters). Press OK to change the
parameter. Use the keys , , ▲ and ▼.
Analog value monitoring ∆, A, B, Ax, Aen
Analog amplifier A, B, Ax
Miscellaneous
Latching relay -
Current impulse relay -
Message texts -
Softkey On/Off
Shift register -
Special function Parameter or process vari-
able visible in a message text
▲
▲
▲
▲
