6. Using a screwdriver, push the interlock to the left. In its
end position the slide interlock engages in the IDEC
SmartRelay Basic.
Repeat steps 3 through 6 to mount further expansion mod-
ules.
Note
The expansion interface on the last expansion module must
be covered.
