Programming IDEC SmartRelay
IDEC SmartRelay Manual 59
The first element of the Co list is the "Input not used" char-
acter, namely the 'x'. Press ▼ or ▲ to select input I1.
Note
Press ▼ to go the start of the Co list: I1, I2 .... to lo, then again 'x'.
Press ▲ to go to the end of the Co list: lo, hi, Q ..... to I1, and once
again 'x'.
Press OK. I1 is now connected to the input of the OR block.
The cursor jumps to the next input of the OR block.
Now you connect input I2 to the input of the OR block. You
already know how to do this:
1. Switch to editing mode: Press OK
2. To select the Co list: Press ▼ or ▲
3. To confirm the Co list with: Press OK
4. To select I2: Press ▼ or ▲
5. To apply I2: Press OK
≥ 1
B1
Q1
≥ 1
Q1
I1
I1
B1
Your complete circuit program
in IDEC SmartRelay up to now:
The display now shows:
