Inficon Micro GC Fusion 2-Module User Manual

INFICON Introduction | 4
074-594-P1H Micro GC Fusion Operating Manual 19 / 319
CAUTION
Ensure the Micro GC Fusion fan exhaust at the back of the instrument is not
blocked and the air flow through the bottom of Micro GC Fusion is
unobstructed.
CAUTION
Carrier gas inlet (rear of instrument) pressure must be between 400-427 kPa
(58-62 psi). Use a dual-stage regulator on the carrier gas cylinder to ensure
the pressure range is maintained.
Exceeding 565 kPa (82 psi) may damage Micro GC Fusion and require factory repair.
CAUTION
Sample inlet gas pressure must be less than 172 kPa (25 psi). Exceeding 172
kPa (25 psi) will damage Micro GC Fusion and require factory repair.
CAUTION
When the Integrated Sample Conditioner is installed, a pressurized sample of
up to 6,895 kPa (1,000 psi) can be connected to the Micro GC Fusion inlet.
Exercise caution when handling the high pressure samples.
CAUTION
Micro GC Fusion is ventilated using an internal fan. The air inlet on the front of
Micro GC Fusion must be kept clean and unobstructed. Allow a minimum of
6.5 cm (2.5 in.) clearance in front of the instrument to allow for proper
ventilation.
WARNING
Safely vent carrier and sample streams - potentially toxic, noxious, asphyxiant
(oxygen displacing) or flammable gases - outside Micro GC Fusion and away
from the operating area. Vent toxic gases to a fume hood, chemical trap, or
reaction medium.

Inficon Micro GC Fusion 2-Module Specifications

General

Brand	Inficon
Model	Micro GC Fusion 2-Module
Category	Measuring Instruments
Language	English
