6 | Installation INFICON
60 / 319 074-594-P1H Micro GC Fusion Operating Man-
ual
CAUTION
Ensure the Micro GC Fusion fan exhaust at the back of the instrument is not
blocked and the air flow through the bottom of Micro GC Fusion is
unobstructed.
CAUTION
Regularly inspect and clean the filter at the bottom of the instrument.
WARNING
Safely vent carrier and sample streams - potentially toxic, noxious, asphyxiant
(oxygen displacing) or flammable gases - outside Micro GC Fusion and away
from the operating area. Vent toxic gases to a fume hood, chemical trap, or
reaction medium.
Avoid venting Micro GC Fusion into drafty areas, such as in front of a heating/
cooling vent
6.1.6 Power Requirement
Standard 100-240 V (ac), 50 to 60 Hz, 5A (minimum) electric outlet for 2-module
systems
Standard 100-240 V (ac), 50 to 60 Hz, 7A (minimum) electric outlet for 4-module
systems
Maximum power for a 2-module Micro GC Fusion system: 300W
Uninterruptible AC power source with surge protection is recommended
Every Micro GC Fusion 2-module system is shipped with a 24 VDC power supply (PN:
952-435-P1S). Always use this power supply to power the instrument.
Every 4-module system contains an internal 24 VDC power supply and does not need
the external supply.
CAUTION
Using an alternative power supply voids the warranty.
