Inficon Micro GC Fusion 2-Module User Manual

5 | Product Overview INFICON
44 / 319 074-594-P1H Micro GC Fusion Operating Man-
ual
5.10 Specifications
5.10.1 Physical Operating Requirements
2-module chassis Specification
Maximum weight 6.2 kg (13.6 lb.)
Dimensions (L x W x H) 46.2 x 19.6 x 25.4 cm (18.2 x 7.7 x 10 in.)
Installation (Overvoltage) Category II per IEC 60664
Power supply input 100 to 240 V (ac), 50 to 60 Hz, 5A
Power supply output 24 V (dc), 10.83 A, 260 Watts maximum
Operating temperature 0°C to 50°C (32°F to 122°F) ambient
Storage temperature -20°C to 60°C (-4°F to 140°F) ambient
Relative humidity 5 to 95% (non-condensing)
Altitude 2,000 m (6,562 ft.)
Pollution degree 2 per EN 61010
Vibration MIL-STD-810F-514.5C, Highway Truck Vibration
4-module chassis Specification
Maximum weight 15.4 kg (33.8 lb.)
Dimensions (L x W x H) 47.5 x 43.2 x 27.1cm (18.7 x 17 x 10.7 in.)
Installation (Overvoltage) Category II per IEC 60664
Power supply input 100 to 240 V (ac), 50 to 60 Hz, 7A
Power supply output 24 V (dc), 42 A, 1008 Watts maximum
Fuse 250 V (ac), 10 A
Operating temperature 0°C to 50°C (32°F to 122°F) ambient
Storage temperature -20°C to 60°C (-4°F to 140°F) ambient
Relative humidity 5 to 95% (non-condensing)
Altitude 2,000 m (6,562 ft.)
Pollution degree 2 per EN 61010
WARNING
Replace only with fuse of the same type and rating to avoid fire and personal
injury.

Inficon Micro GC Fusion 2-Module Specifications

General

Brand	Inficon
Model	Micro GC Fusion 2-Module
Category	Measuring Instruments
Language	English
