9.5 View System Status
Click the
icon to display the
System Status
screen.
The
System Status
screen displays:
• module part number and serial number
• installed module information
• temperature and pressure set points and real time readings
Once a method starts loading, the actual temperature and pressure readings
equilibrate to the set points defined in the method. The
System Status
window
displays both the set points and the actual readings (in parentheses) of the
temperatures and pressures for the Micro GC Fusion analytical components.
In the System Status window, Module A is displayed above Module B.
Physically in the 2-module Micro GC Fusion instrument, Module A is the
bottom module and Module B is the top module.
