Intel® Server Board S2600CW Family TPS Appendix C: BMC Sensor Tables
Revision 2.4
169
Full Sensor Name
(Sensor name in SDR)
Senso
r #
Platform
Applicabili
ty
Sensor Type Event/Rea
ding Type
Event Offset
Triggers
Contrib. To
System
Status
Assert
/De-
assert
Readab
le
Value/
Offsets
Event
Data
Rearm Stand-
by
Global Aggregate
Temperature Margin 8
(Agg Therm Mrgn 8)
CFh
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Baseboard +12V
(BB +12.0V)
D0h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Voltage Fault
(Voltage Fault)
D1h All
Voltage
02h
Discrete
03h
01 – Asserted - - - - A -
Baseboard CMOS Battery
(BB +3.3V Vbat)
DEh All
Voltage
02h
Threshold
01h
[l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Hot-swap Backplane 4
Temperature
(HSBP 4 Temp)
E0h
Chassis-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Rear Hard Disk Drive 0 -1
Status
(Rear HDD 0 - 1 Stat)
E2h
-
E3h
Chassis-
specific
Drive Slot
0Dh
Sensor
Specific
6Fh
00 - Drive Presence
OK
As
and
De
– Trig Offset A X
01- Drive Fault
Degraded
07 - Rebuild/Remap
in progress
Degraded
Hard Disk Drive 0 -14 Status
(HDD 0 - 14 Status)
F0h
-
FEh
Chassis-
specific
Drive Slot
0Dh
Sensor
Specific
6Fh
00 - Drive Presence OK
As
and
De
– Trig Offset A X
Notes:
1. Redundancy sensors are present only on systems with appropriate hardware to support redundancy (for instance, fan or power supply).
2. This is applicable only when the system does not support redundant fans. When fan redundancy is supported, then the contribution to system state is
driven by the fan redundancy sensor.
