Adjustingthemobilitydevicetotheuser'sseatingposture
6.2.1Adjustingtheremoteforthelengthofthe
user'sarm(allseatsystems)
1.LoosenwingboltA.
2.Shifttheremoteforwardsorbackwardstothedesireddistance.
3.Retightenthebolt.
6.2.2Adjustingtheheightoftheremote(onlyfor
swing–awayremoteholders)
Requirements:
•1x6mmAllenkey
1.LoosentheAllenscrewA.
2.Adjusttheremotetothedesiredheight.
3.Re-tightentheAllenscrew.
6.2.3Swivellingtheremotetotheside
Ifyourmobilitydeviceisfittedwithaswing-awayremoteholder,
thentheremotecanbemovedawaytotheside,forexample,to
driveupclosetoatable.
6.3Adjustmentoptionsforstandardarmrests
6.3.1Changingthearmsupportposition
Requirements:
•1xAllenkey3mm
Thearmsupporthas12possiblepositions.
1529686-P31
