Invacare®Storm®⁴
3.
Setthedesiredangle.
4.
Turntheknobclockwisetotightenit.
7.4.3Settingtheendstopofthelegrest
Requirements:
•1x10mmopen-endedspanner
1.
Theendpositionofthelegrestisdeterminedbymeansofa
rubberstop(1).
2.
TherubberstopcanbescrewedinoroutAorpushedupor
downB.
3.
Loosenthelockingknob(1)counter-clockwiseatleastoneturn.
