Invacare®Storm®⁴
6.7.3AdjustingthebackseatangleontheEasy-Adapt
seatingsystem
1.Adjusttheanglebyturningthehandwheel(1).
6.7.4Adjustingtheheightofthebackrest(Modulite
seatunit)
Thefollowingsectiondescribestheproceduresforadjustingthe
heightofthebackrestplate.
NOTE
–Theslingbackisonlyavailableinfixedheightsof48
and54cm.
Requirements:
•1x5mmAllenkey
1.LoosenthebackrestplatescrewsAandB.
Donotremovethescrews!
2.Movethebackrestplatetotherequiredheight.
3.Re-tightenthescrews.
6.7.5Adjustingthewidthofthebackrest(Modulite
seatunit)
Youcanadjustthebackrestplatewidthtoacertaindegreeby
adjustingthefrontplate,e.g.inordertoadjustthebackrestplatein
linewiththeseatcushion.Fairlylargeadjustmentsmustbemadeby
aservicetechniciantotherearplateandareoutlinedintheservice
instructionsforthismobilitydevice.
401529686-P
