Invacare Storm 4 - Adjusting the Seat Depth Without Replacing the Seat Support Plate

Invacare®Storm®⁴
Seat
depth
incm
Holesused
infrontseat
frameorder
no.:1524550
Holesused
inrearseat
frameorder
no.:1524555
Seat
support
plate
required
386&7A&B
41
5&7
A&C
434&6A&C
SHORT
orderno.
1526437
434&6A&C
463&5A&C
482&4A&C
MEDIUM
orderno.
1526438
482&4A&C
511&3A&C
531&2B&C
LONG
orderno.
1526439
2.Adjusttheseatdepthasdescribedinthefollowingchapter:
-Iftheseatsupportplatedoesnotneedtobereplaced,please
refertochapter6.13.3Adjustingtheseatdepthwithoutreplacing
theseatsupportplate,page50
.
-Iftheseatsupportplatedoesneedtobereplaced,pleaserefer
tochapter6.13.4Adjustingtheseatdepthwithreplacingtheseat
supportplate,page51
.
6.13.3Adjustingtheseatdepthwithoutreplacing
theseatsupportplate
Explodeddrawingofseatsupport
Disassembly:
1.Removethearmrests.
2.Removetheseatcushion.
3.Removethecoverplates(1).
4.UndoandremovethetwoAllenscrews(8)whicharelocated
onthesideattherearoftheseatsupportplate,andconnect
thesetothecrossmembers(4).
501529686-P
