Invacare Storm 4 - Adjustment Options for Parallel Sliding Armrests; Setting the Height of the Parallel Sliding Armrests; Adjusting the Angle of the Armpad on the Parallel Sliding Armrests

Adjustingthemobilitydevicetotheuser'sseatingposture
Requirements:
•Allenkey8mm
1.Loosenscrew(1).
2.Adjustarmresttorequiredposition.
3.Retightenthescrew.
4.Repeatthisprocedureforthesecondarmrest.
6.4Adjustmentoptionsforparallelsliding
armrests
6.4.1Settingtheheightoftheparallelsliding
armrests
Theheightoftheparallelslidingarmrestissetusingthearmrestangle.
1.
Releasetheknobtoadjustthearmrestangle(1).
2.
Settheangleforthearmrest.
3.Retightentheknob.
Afteradjustingthearmrestheight,theangleofthearmpadneedsto
beadjusted.Referto6.4.2Adjustingtheangleofthearmpadonthe
parallelslidingarmrests,page33
.
6.4.2Adjustingtheangleofthearmpadonthe
parallelslidingarmrests
Requirements:
•Allenkey5mm
1529686-P33
