Invacare Storm 4 - Setting the Angle

Invacare®Storm®⁴
1.Presstheunlockingbutton(1)andswivelthefootrest/legrest
outward.
2.Removethefootrest/legrestinanupwarddirection.
7.3.2Settingtheangle
CAUTION!
Riskofinjuryduetoincorrectadjustmentofthe
footrestsandlegrests
–Beforeandduringeveryjourneyitisimperativeto
ensurethatthelegrestscontactneitherthecaster
wheelsnortheground
Requirements:
•1x6mmAllenkey
1.
Loosenthescrew(1)usingtheAllenkey.
2.Ifthefootrestcannotbemovedafterlooseningthescrew,
positionametalpininthedesignatedborehole(2)andusea
hammertoknockonthislightly.Theclampingmechanismin
theinteriorofthefootrestwillbereleasedbythis.Repeatthe
procedurefromtheothersideofthefootrestifnecessary.
3.
Loosenthescrew(1)usingtheAllenkey.
4.Setthedesiredangle.
5.Re-tightenthescrew.
601529686-P
