Invacare Storm 4 - Adjusting the Seat Depth

Adjustingthemobilitydevicetotheuser'sseatingposture
Explodeddrawingofseatsupport
1.Removetheseatcushion.
2.Removethecoverplates(1).
3.UndothetwoAllenscrews(6)attherearonthecrossmember
andremovethem.
4.UndothetwoAllenscrews(9)atthefrontontheseatsupport
plateandremovethem.
5.LoosenthefourAllenscrews(7)and(8)whicharelocatedatthe
frontandbacktothesidesoftheseatsupportplatetorelease
tensionsothattheplatecanbemovedmoreeasily.Donot,
however,removethesescrewscompletely.
6.Pullorpushtheseatsupportplate(2)therequiredwidth.A
scale(3)hasbeenfittedtothebottompartoftheseatsupport.
Usethisscaletoreadofftheseatwidthincentimeters.
7.Repeattheseoperationsontheothersideoftheseat.
8.Nowtightenallthescrewsagain.
6.13.2Adjustingtheseatdepth
NOTE
–Alsorefertothepreviouschapterentitled6.13.1
Adjustingseatwidth,page48
.
–Theseatdepthcanbeadjustedinstagesbetween380
and530mm.
Requirements:
•4mmAllenkey
•8mmjawspanner
•obliquepliers
•cablebinder
NOTE
–Particularholesintheseatsupportmustbeusedto
thescrewsdependingontherequiredseatdepth.It
mayalsobenecessarytoreplacetheseatsupport
plate.
1.Pleaseusethefollowingfiguresandthetabletodeterminewhich
holesneedtobeusedfortherequiredseatdepth,andtherefore
whethertheseatsupportplateneedstobereplacedornot.
1529686-P49
