6.12.1Laterallyadjustingthetray
1.Loosenthewing-screw(1).
2.Adjustthetraytowardstheleftorright.
3.Re-tightenwing-screw.
6.12.2Adjustingthedepthofthetray/removing
thetray
1.Loosenthewing-screw(1).
2.Adjustthetabletothedesireddepth(orremoveitentirely).
3.Re-tightenthescrew.
6.12.3Swingingthetrayawaytotheside
Thetraycanbeswivelledupandawaytothesidetoallowtheuser
togetinandoutofthemobilitydevice.
CAUTION!
Riskofinjury!Whenthetrayisraiseditdoesnot
lockinplaceinthisposition!
–Donottiltthetrayupandleaveitleaninginthis
position.
–Neverattempttodrivewiththetraytiltedup.
–Alwayslowerthetrayinacontrolledmanner.
6.13Seatsupport
6.13.1Adjustingseatwidth
NOTE
–Alsorefertothefollowingchapterentitled6.13.2
Adjustingtheseatdepth,page49
.
–Theseatwidthcanbeadjustedinstagesbetween380
and530mm.
Requirements:
•4mmAllenkey
