Informationregardingoperationofthelifterat
temperaturesoflessthan0°C
–Invacaremobilityaidsarefittedwithsafetymechanisms
thatpreventcapacityoverloadoftheelectronic
components.Atoperatingtemperaturesbelow
freezingpointthiscan,inparticular,leadtothelifter
actuatorbeingshutdownafterapprox.1second
operatingtime.
–Theliftercanberaisedorloweredgraduallyby
repeatedlyoperatingthejoystick.Inmanycasesthis
generatessufficientheatfortheactuatortooperate
asnormal.
NOTE-speedlimiter
–Thelifterisfittedwithsensorswhichreducethe
mobilitydevicespeedassoonasthelifterisraised
aboveacertainpoint.
–Thistakesplacetoguaranteethetippingstabilityofthe
mobilitydeviceandtoavoiddamagetothelegrests.
–Ifthespeedlimitisactivated,acorrespondingblink
codeisdisplayedontheremoteorareduceddrive
levelissetautomatically.Pleaserefertotheremote
manualformoreinformation.
–Toreapplynormalspeed,runthelifterdownuntilthe
statusdisplaystopsblinking.
CAUTION!
Riskoftipping,ifthespeedlimitersensorsfail
whenthelifterisraised
–Ifyoufindthatthespeedreductionfunctionisnot
workingwhenthelifterisraised,donotdrivewith
thelifterraisedandimmediatelycontactanauthorized
Invacaredealer.
6.11Adjustingthetrunksupport(Easy-Adapt
seatingsystem)
Thetrunksupportscanbeadjustedinwidth,heightanddepth.
6.11.1Adjustingthewidth
1.Loosenthehandscrews(1).
2.Adjustthetrunksupporttotherequiredwidth.
3.Retightenthehandscrewsagain.
