Adjustingthemobilitydevicetotheuser'sseatingposture
NOTE
–Activatethemotorbrakes(engagemotor)before
adjustingtheseatangle.
–Onlyadjusttheseatanglemanuallyifnobodyissitting
intheseat.
Requirements:
•1x6mmAllenkey
1.Switchthepowersupplyoff(ON/OFFkey).
2.UnscrewAllenscrews(1).
3.Adjusttheseatanglebyraisingorloweringtheseat.
4.InserttheAllenscrewsagainandtighten.
6.7Adjustingthebackrest
CAUTION!
Adjustingtheseattiltorthebackrestangle
changesthegeometryofthemobilitydeviceand
directlyinfluencesitsdynamicstability!
–Fordetailsregardingdynamicstability,negotiating
gradientsandobstaclesandthecorrectadjustment
ofseattiltorbackrestangle,referto5.3Taking
Obstacles,page24
andDrivingupanddowngradients.
6.7.1Electrical
Consulttheusermanualforyourremoteforinformationabout
electricaladjustment.
6.7.2Adjustingthebackrest(standardseat)—
manuallywithhandscrews
1.Removethescrews(1)onbothsidesofthebackrestthathold
itinposition.
2.Setthebackresttothedesiredanglebyselectingacombination
ofoneofthetwoholesinthebackrestframe,andoneofthesix
holesinthemetalfixationplate.
3.Re-positionscrewsandtightenthem.
1529686-P39
