Adjustingthemobilitydevicetotheuser'sseatingposture
1.TurnthewheelAtotheplussign,tosethardershock
absorbance.
10isthehardestlevelofshockabsorbance.
Adjustingtheshockabsorbancesofter
1.Turnthewheel(A)totheminussign,tosetsoftershock
absorbance.
10isthesoftestlevelofshockabsorbance.
6.16Adjustingorremovingtheluggagecarrier
Riskofdamageasaresultofcollisions
Partsofthemobilitydevicemaybedamagedifthe
luggagecarriercollideswiththeseatduringseatangleor
backrestadjustment.
–Ensurethattheluggagecarrierisoutoftherangeof
bothseatangleandbackrestadjustment.
Riskofbreakageduetoexcessiveload
Theluggagecarriercanbreakiftoogreataloadis
applied.
–Themaximumpermittedloadontheluggagecarrier
is10kg.
1.Opentheclamplevers(1)oftheluggagecarrierbracket.
2.Slidetheluggagecarrierforwardorbackwardorremoveit.
3.Closetheclampleversoftheluggagecarrierbracket.
