7.5.6Unlockingandswivellingthecalfpadbackward
whenalighting
1.
Pressthecalfpadstraightdown.
2.
Unlockthelegrestandswiveloutward.
Thecalfpadswivelsbackwardonitsown.
3.
Liftlegovertheheelstrapandplaceontheground.
7.5.7Adjustingtheangle–adjustablefootplate
Requirements:
•1x5mmAllenkey
1.UsetheAllenkeytoloosenbothsetscrewsonthefootplate.
2.Adjusttothedesiredangle.
3.Re-tightenthescrews.
7.5.8Adjustingtheangle–anddepth–adjustablefoot
plate
Requirements:
•1x5mmAllenkey
