Invacare®Storm®⁴
6.5.5Adjustingtheseatdepth
NOTE
–Theseatdepthhasamajorinfluenceontheselection
ofthecenterofgravityoftheseat.Thisimpactsits
dynamicstability.Ifyoumakeamajorchangetothe
seatdepththecenterofgravityoftheseatmustalso
beadjusted.See"Adjustingthecenterofgravityof
theseat"intheserviceinstructionsforthismobility
device.Theserviceinstructionscanbeorderedfrom
Invacare.However,theycontaininstructionsfor
speciallytrainedtechniciansanddescribeoperations
thatarenotintendedfortheenduser.
NOTE
–Thenumbersonthescaleontheseatserveasaguide.
Theydonotstipulateanydimensionssuchasseat
depthincentimeters.
Requirements:
•1x6mmAllenkey
1.Onbothsides,loosenthebottombackrestscrewA.
Donotremovethescrews!
2.Movethebackresttotherequiredseatdepth.
Youcanadjusttheseatdepthsteplessly.UsescaleBontheseat
asaguideforthispurpose.
Ensurethatthesameseatdepthissetonbothsides.
3.Re-tightenthescrews.
6.6Adjustingtheseatangle
CAUTION!
Adjustingtheseattiltorthebackrestangle
changesthegeometryofthemobilitydeviceand
directlyinfluencesitsdynamicstability!
–Fordetailsregardingdynamicstability,negotiating
gradientsandobstaclesandthecorrectadjustment
ofseattiltorbackrestangle,referto5.3Taking
Obstacles,page24
andDrivingupanddowngradients.
6.6.1Electrical
Consulttheusermanualforyourremoteforinformationabout
electricaladjustment.
6.6.2Manual
Theseatangleisadjustedusinganadjustingmechanism,which
consistsof2perforatedstripswhichcanbepushedagainsteach
other.Theadjustingmechanismisatthefrontundertheseatframe.
Whenadjustingtheseatangle,ensurethatbothfixingscrewsare
alwaysusedtofixtheadjustingmechanism!
