Invacare®Storm®⁴
9.4RepairInstructions
Importantinformationaboutmaintenancework
tools!
–Somemaintenanceworkwhichisdescribedinthis
manualandcanbecarriedoutbytheuserwithout
problemsrequirethecorrecttoolsforproperwork.
Ifyoudonothavethecorrecttoolavailablewedo
notrecommendthatyoutrytocarryouttherelevant
work.Inthiscase,weurgentlyrecommendthatyou
contactanauthorisedspecialistworkshop.
Thefollowingareinstructionsonmaintenanceandrepairsthatcan
beperformedbytheuser.Forthespecificationsofspareparts
pleasesee12Technicaldata,page95
,orconsulttheservicemanual,
availablefromInvacare(inthisconnectionpleaseseetheaddresses
andphonenumbersattheendofthisusermanual).Incaseyou
requireassistance,pleasecontactyourInvacaredealer.
CAUTION!
Riskofdamageorinjuryifthevehicleis
accidentallysetintomotionduringrepairs
–Switchthepoweroff(ON/OFFButton).
–Engagethemotors.
–Securethevehicleagainstrollingawaybyplacing
wedgesunderthewheels.
CAUTION!
Riskofhandsandfeetbeingcrushedbythe
weightofthewheelchair
–Payattentiontoyourhandsandfeet.
–Usethecorrectliftingtechniques.
9.4.1Repairingtirepunctures(wheelrimtype
3.00-8")
CAUTION!
Riskofinjury
Ifthewheelhasbeeninsufficientlytightenedduring
assembly,itcanbecomeloosenedduringdriving.
–Whenreassemblingthedrivewheels,tightentheAllen
screwsatatorqueof30Nm.
–Secureallscrewsusingasuitableblocker(e.g.Loctite
243).
Requirements:
•Allenkey–open-endedspanner6mm
•Torquespanner
•Repairkitfortirerepairoranewinnertube
•Talcumpowder
•ScrewblockerLoctite(e.g.Loctite243)
Removingthewheel
1.Blockupthevehicle(placewoodenblocksunderframe).
2.Unscrewthescrew(1).
3.Removethewheelfromthehub.
821529686-P
