7.4.4Adjustingthelengthofthelegrest
CAUTION!
Riskofinjuryduetoincorrectadjustmentofthe
footrestsandlegrests
–Beforeandduringeveryjourneyitisimperativeto
ensurethatthelegrestscontactneitherthecaster
wheelsnortheground
Requirements:
•1x5mmAllenkey
1.Usethespannertoloosenthescrew(1).
2.Adjusttothedesiredlength.
3.Re-tightenthescrew.
7.4.5Adjustingthedepthofthecalfpad
Thedepthofthecalfpadcanbeadjustedviatheholdingplate.The
holdingplateholecombinationsallow5differentdepthsettings.
Requirements:
•1x10mmopen-endedspanner
1.Usetheopen-endedspannertoloosenthenut(1)andremove.
2.Adjusttothedesireddepth.Pleaseobservethattheroundholes
areintendedforthecalfpadretainingscrewandtheoblong
holesfortheagletwithoutthread.
3.Screwthenutbackonandtighten.
7.4.6Adjustingtheheightofthecalfpad
Requirements:
•1x4mmAllenkey
