Invacare Storm 4 - Adjusting the Position of the Armrest in Depth; Adjusting the Seat Width

Adjustingthemobilitydevicetotheuser'sseatingposture
Dependingontheside,thescrewisaccessiblefromthe
frontortherear.
Requirements:
•Allenkey8mm
1.LoosenscrewA.
2.Adjustarmresttorequiredposition.
3.Retightenthescrew.
4.Repeatthisprocedureforthesecondarmrest.
6.5.3Adjustingthepositionofthearmrestindepth
Prerequisites:
•1x6mmAllenkey
1.LoosenthescrewsAandmovethearmrestlengthwise.
2.Tightenthescrews.
6.5.4Adjustingtheseatwidth
Thetelescopicseatsupportcanbeadjustedinfourstages.Theseat
widthcanthusbeadjustedtogetherwiththeadjustableseatplateor
theadjustableslingseat.
Thedescriptionofhowthewidthisadjustediscontainedinthe
serviceinstructionsforthismobilitydevice.Theserviceinstructions
canbeorderedfromInvacare.However,theycontaininstructions
forspeciallytrainedservicetechniciansanddescribeoperationsthat
arenotintendedfortheenduser.
1529686-P37
