Invacare®Storm®⁴
3.
Pullthelever(1).
Thefootplatesriseupautomatically.
4.Letgothelever(1)andputyourfeetonthefootplates.
Riskofdamagetothelegrest
–Alwaysmakesurethatthefootplatesarefullyraised
totheuppermostpositionbeforeadjustingtheangle
ofthelegrest.
–Disregardingthisadvicewillcausedamagetoyour
legrest.
Adjustingthelegrest
1.Nowyoucanadjusttheangleofthelegrest.
7.2Center-mountedlegrests—Adjustable
legrest
7.2.1Adjustingtheangle
Requirements:
•1x10mmopen-endedspanner
1.Usetheopen-endedspannertoloosenthecounternut(1).
2.Movethelegresttothedesiredpositionbyturningthespindle
(2).
3.Tightenthecounternut.
7.2.2Adjustingthelengthofthelegrest
Requirements:
•1x5mmsocketheadspanner
