Invacare®Storm®⁴
1.
Putthearmrestintheverticalposition.
2.Releasetheinteriorbolts(1)withtheAllenkey.
3.
Positionthearmresthorizontally.
4.Re-tightenthebolts.
MakesurethattheNordlockwashersusedarere-inserted.
6.5AdjustmentoptionsfortheModuliteseat
unit
6.5.1Adjustingtheheightofthearmrests
1.LoosenthewingscrewA.
2.Setthearmresttothedesiredheight.
3.Re-tightenthewingscrew.
6.5.2Adjustingthewidthofthearmrests
WARNING!
Seriousinjuryhazardifoneofthearmrests
fallsoutofitsbracketbecausetheyhavebeen
adjustedtoawidthwhichexceedsthepermissible
value
–Thewidthadjustmentisfittedwithsmallstickerswith
markingsandtheword"STOP".Thearmrestsmust
neverbepulledoutfurtherthanthepointatwhich
theword"STOP"iscompletelylegible.
–Alwaystightenthefixingscrewsproperlyonce
adjustmentshavebeencompleted.
