7.4.8Adjustingtheangle–adjustablefootplate
Requirements:
•1x5mmAllenkey
1.UsetheAllenkeytoloosenbothsetscrewsonthefootplate.
2.Adjusttothedesiredangle.
3.Re-tightenthescrews.
7.4.9Adjustingtheangle–anddepth–adjustablefoot
plate
Requirements:
•1x5mmAllenkey
1.UsetheAllenkeytoloosenthesetscrewonthefootplate(1).
2.Adjustthefootplatetothedesiredangleordepth.
3.Re-tightenthescrew.
7.5ADElegrests
7.5.1Swivellingthelegrestoutwardand/orremoving
Thesmallunlockingbuttonislocatedontheuppersectionofthe
legrest.Whenthelegrestisunlocked,itcanbeswivelledinward
oroutwardwhengettingintowheelchairaswellasbeingremoved
completely.
