Invacare Storm 4 - Setting the Height of the Armrests; Adjusting the Width of the Armrests

Invacare®Storm®⁴
1.Tochangethepositionofthearmsupport,loosenthescrew
(1)andremoveit.
2.Thepositionofthearmsupportisadjustedbyselectinga
combinationofscrewholesinthearmsupportandthedrillholes
inthefixingplate.
3.Repositionthescrewsandtighten.
6.3.2Settingtheheightofthearmrests
Requirements:
•Allenkey3mm
1.Unscrewscrew(1)withAllenkey.
2.Adjustarmresttorequiredheight.
3.Retightenthescrew.
6.3.3Adjustingthewidthofthearmrests
WARNING!
Seriousinjuryhazardifoneofthearmrests
fallsoutofitsbracketbecausetheyhavebeen
adjustedtoawidthwhichexceedsthepermissible
value!
–Thewidthadjustmentisfittedwithsmallstickerswith
markingsandtheword"STOP"!Thearmrestsmust
neverbepulledoutfurtherthanthepointatwhich
theword"STOP"iscompletelylegible!
–Alwaystightenthefixingscrewsproperlyonce
adjustmentshavebeencompleted!
321529686-P
