Invacare Storm 4 - Angle-Adjustable Footboard; Adjusting the Width of Side-Mounted Legrests

Invacare®Storm®⁴
1.UsetheAllenkeytoloosenthesetscrewonthefootplate(1).
2.Adjustthefootplatetothedesiredangleordepth.
3.Re-tightenthescrew.
7.6Angle-adjustablefootboard
Requirements:
•TorxspannerT25
•Allenkey5mm
1.
Releasethescrews(1)withtheTorxspannerandremove.
2.Adjusttorequiredwidth.
3.Retightenthebolts.
4.Gluetheanti-sliprubbermattothefootboard.
5.
Loosenthelockingscrew(1)onbothsideswiththemmAllen
key.
6.Adjustthefootboardtotherequiredangle.
7.Retightenthebolts.
7.7Adjustingthewidthofside-mounted
legrests
Requirements:
•13mmopen-endedspanner
Thescrewsthatallowwidthadjustmentofside-mountedlegrests
arelocatedundertheseat(1).
721529686-P
