Invacare Storm 4 - Adjusting the Mobility of the Parallel Sliding Armrests; Adjusting the Arm Support Positions for the Parallel Sliding Armrests

Adjustingthemobilitydevicetotheuser'sseatingposture
8.Repeattheprocedurefortheotherarmrest.
9.
Replacethebackrestcover(2).Whendoingso,ensurethatthe
recessesinthesidesarelocatedcorrectly.
10.Retightentheboltsonbothsidesofthebackrestcover(1)again.
Thephotographonlyshowstheboltsontheleft-handside.
6.4.4Adjustingthemobilityoftheparallelsliding
armrests
Theflexibilityoftheparallelslidingarmrestcanbeadjustedtoeasier
orstiffer.
Requirements:
•Allenkey5mm
1.Tomakethearmresteasiertomove,releasetheboltofthe
adjustingwrench(1)withtheAllenkey.
2.Tomakethearmrestmoredifficulttomove,tightentheboltof
theadjustingwrench(1)withtheAllenkey.
6.4.5Adjustingthearmsupportpositionsforthe
parallelslidingarmrests
Requirements:
•Allenkey5mm
1529686-P35
