Goodrive300-01A-RT series integrated machine Function description
-75-
Function
code
Name
Description
Default
Modify
1: Maintenance required; 0: Normal
BIT5: Reserved
BIT6: Auxiliary temperature signal
1: Auxiliary temperature signal fault; 0:
Normal
BIT7: Reserved
BIT8: Auxiliary temperature pre-alarm signal
1: Temperature pre-alarm; 0: Normal
BIT9: Reserved
BIT10: Auxiliary temperature alarm signal
1: Temperature alarm; 0: Normal
BIT11: Maintenance timeout remainder
1: Maintenance timeout remainder; 0:
Normal
BIT12: Phase sequence remainder
1: Fault; 0: Normal
BIT13: Solenoid valve overcurrent signal
1: Solenoid valve alarm, 0: Normal
BIT14: PTC overtemperature signal
1: PTC overtemperature alarm; 0: Normal
BIT15: Emergency stop signal
1: Emergency stop signal alarm, 0: Normal
P19.15
Device state
0: Standby
1: Run
2: Fault
3: Emergency stop
4: Undervoltage
5: Alarm
6: Sleep
7: In stopping
8: Restart delay
0
P19.16
Accumulated running
time
Display range: 065535h
0
P19.17
Accumulated
load-carrying running
time
0
P19.18
Restart count-down
Display the remaining time of restart delay
(P18.16). After the system stops, it will enter
0s
