2 System& Admin Information
2.1 System capacities for eMG and UCP
iPECS eMG is available in several hardware configurations based on the Main board of the KSU. The
software will structure a database for the maximum possible station and CO/IP Line configurations upon
initialization. Thus, the software port count capacities will differ from the hardware count. However, the
hardware limitations always apply.
The total System ports supported by the software include the Station ports, CO/IP Line ports, and ports for
various options, including the integrated AA/VM, Miscellaneous ports, etc. The hardware and software
capacities are the same as the Station and CO/IP Line ports. The capacities relative to the software are
provided in the table below.
Table 2.1-1 eMG80Software Capacity
Item
Capacity
CO/Trunk lines
Max. 74
Stations
Max. 140
Attendants
4
LAN port
2(1 each, KSU and VVMU)
Modem Channel
1(MODU)
Serial Port(RS-232C)
1
USB(2.0) Host port
1
Alarm/Doorbell input
2 (1 per KSU)
External Control Relays
2 (1 per KSU)
Music Source Inputs
1 Internal: select one of 13 melodies
1 External source input
5 SLT ports
3 VSF announcements
Power Fail Circuit
Max. 6 (1 per KSU, EKSU, CH204, CH408, CS416)
VSF Device 1: Built-in AA/VM
- w/MEMU
- w/MEMU2
VSF Device 2 (VVMU)
8 channels(2 Chan. by default, 1Channel by license), 1 hour
15 hours(no license needed)
60 hours(no license needed)
8 channels (by license) & 15 hours(by license), 1 hour(by default)
Conference channels
148 channels/13 parties per group
Max. WTIB
1
DECT Phones
48
Built-in VoIP channels
8(2 channels by default, 6 channels by license)
VVMU VoIP channels– eMG80
8(by license)
IP Stations and SIP Trunks
48 port (32 Stations+16 SIP Trunks)
External Page
1 port
Internal Page
35 zones
System Speed Dial
3000 numbers, 25 digits each
