iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
338
Register LM
device directly
This option enables LM (Local system) device to register CM
(Central system) directly without T-NET by setting ON.
It is an LM system register interval.
If it Is not zero, then the LM system will be registered to CM
sequentially.
4.4.12.3 T-NET LM Attributes -PGM 332
Selecting T-Net LM Attributes will display as below. Click the [Save] button after changing Value.
Figure 4.4.12.3-1 T-NET LM Attributes
The CM (Central iPECS system) must be programmed with the MAC and IP address of each LM (Local
iPECS system) in the Centralized Control network and the maximum configuration of each LM. Up to 100
Local iPECS systems (LMs) may be defined, and configuration entered.
The port counts define the ports allocated in the CM database for use by devices registered to the LM. The
number of ports defined in the database for each LM in PGM 331 must be equal to or less than the ports
defined in the CM to register properly.
Table 4.4.12.3-1 T-NET LM ATTRIBUTES
This field defines the MAC address of the LM that will be part of the
T-NET environment and is used by the CM for authorization.
This field is the IP address of the LM.
In the T-NET environment, the IP KTS protocol signaling the UDP
port is defined. At present, this field is not used, do not change this
port number.
