iPECS UCP100 - VMEX Station Data - PGM 215

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
285
4.4.8.10 VMEX Station Data - PGM 215
Selecting VMEX Station data will display the VMEX Station Data input page as shown in the following figure.
Enter a range, and click [Load] to view the VMEX Data for all stations in the range. Use the checkboxes to
indicate the VMEX Station Data to modify. After modifying the data, click [Save] to store the VMEX Station
Data.
Enter VMEX Station Index Range: eMG80/100: 1-140 / eMG800: 1-1200 / UCP: 1-2400
Figure 4.4.8.10-1 VMEX Station Data
The Virtual Mobile Extension feature permits a remote mobile phone to act as a station within the system
employing SIP. Various parameters, as shown in the following table, must be configured for the Station data
for proper operation.
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
Station
Number
The station number of the VMEX can be modified. The VMEX station
number must not conflict with other numbering plans. The station
number can be modified here or in PGM 105 and is affected by the 8
Digit Table
Station
Number
Mobile
Number
The Caller Id of the Mobile phone must be entered to allow the system
to recognize the VMEX phone. The mobile number here must match
the number in the SIP From the header.
DID Number
The DID number associated with the VMEX must be configured to
allow for recognition of calls to the VMEX.
Connection
Table
An index to the Connection Table PGM 216 must be entered. One of
ten indices can be assigned permitting the use of multiple SIP Call
servers.
0 ~ 10
Proxy
Address
The SIP Proxy for the VMEX must be configured for access to the
VMEX.
Fail-over
The index (Station Number) of the Mobile Extension Table (PGM 236)
can be assigned for Fail-over operation. In this case, the Table entry
must be configured for fail-over operation.
Station
Number
