4.3.16 VIRTUAL TRACE DIP-SWITCH — PGM 452
The Virtual Trace Dip-switch is used to enable and disable traces for various functions as defined in Table
3.3.16-1.
PROCEDURE:
VIRTUAL TRACE DIP SW
PRESS FLEX KEY (01-22)
Press the [PGM] button and dial 452.
To enable trace, press the desired trace button 1-9. The Flex button
LEDs indicate trace setting, On/Off, press the desired Flex button to
toggle Trace Enable,
- LED on: trace enable
- LED off: trace disabled.
To enable selected trace settings, press the [Save] button.
Table 3.3.16-1 VIRTUAL TRACE DIP-SWITCH (PGM 452)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
VIRTUAL TRACE DIP SW
CALL TRACE : (OFF)
‘Call Trace’ is enabled for output.
0: OFF
1: ON
OFF
2
VIRTUAL TRACE DIP SW
VOIP TRACE : (OFF)
VoIP Trace is enabled for output.
0: OFF
1: ON
OFF
3
VIRTUAL TRACE DIP SW
HTTP TRACE : (OFF)
HTTP Trace is enabled for output.
0: OFF
1: ON
OFF
4
VIRTUAL TRACE DIP SW
MULTICAST TRACE : (OFF)
Multicast Data (normally registration
data between MPB and local mode
device) Trace is enabled for output.
0: OFF
1: ON
OFF
5
VIRTUAL TRACE DIP SW
CTI TRACE : (OFF)
CTI Device Trace is enabled for output.
0: OFF
1: ON
OFF
6
VIRTUAL TRACE DIP SW
RAW DATA-TRACE : (OFF)
Detailed Data Trace is enabled.
0: OFF
1: ON
OFF
7
VIRTUAL TRACE DIP SW
MPMP TRACE: (OFF)
MPB to MPB Data Trace is enabled for
output.
0: OFF
1: ON
OFF
8
VIRTUAL TRACE DIP SW
CPU RE TRACE: (OFF)
CPU Redundancy Data Trace is
enabled for output.It is not used.
0: OFF
1: ON
OFF
9
VIRTUAL TRACE DIP SW
MISU/VMIU TRACE:( OFF)
MISU/VMIU Trace is enabled for output.
0: OFF
1: ON
OFF
