4.4.9.3 LCR DMT (Digit Modification Table) - PGM 222
Selecting LCRDMT (Digit Modification Table) will display the LCR-DMT data entry page. Enter the DMT Table
Index range, then click [Load] to modify the DMT data. Click the [Save] button after changing Value.
Figure 4.4.9.3-1 LCR Digit Modification Table
Using the index determined from the LCR Leading Digits Table analysis, the dialed number is modified
following the Digit Modification Table and sent over the CO/IP group assigned for the index.
Digits of the dialed number can be deleted based on the “Removal Position” and “Number of digits to be
removed” entries, and a digit stream can be inserted in the resulting number. Counting from the first dialed
digit, the Removal Position defines the location of the digit where removal begins and, the number of digits to
be removed defines the number of digits to remove. The “Add Digits” are then inserted in the resulting number
at the digit position assigned by the Add Position entry. The resulting number is then dialed over the CO/IP
path assigned. If the assigned path is not available, the “Alternate DMT index” is used to determine the
number and CO/IP path to be used.
This entry defines the digit stream to insert in the
number after digit removal. Digits 0~9, ‛*, ‘‛#, ‘and
special characters,
P: timed Pause
D: Dial tone detect
F: Billing station number
This entry defines the position of the digit where
removal is to begin, starting with the 1st dialed digit
(01).
This entry defines the position in the number after digit
removal, where the Add Digits are inserted.
