4.3.9.15 Digit Conversion Tables – PGM 270
The Digit Conversion Table index is assigned to the Station and CO line. And the digit conversion can be
applied according to the Apply Time Type (Unconditional, Day/Night/Timed, or LCR Day/Time) differently. Each
Table includes 200 entries of up to 16 digits; entries in the Tables can be any digit (01–15), or “*,” “#.” Each
Index can be applied by Apply Option. (All/Station/CO line/Disable)
PROCEDURE:
DIGIT CONVERSION TABLE
ENTER TABLE NO (01–15)
Press the [PGM] button and dial 270 and enter the table number (Ex.
01).(eMG80/100 :1-15 / eMG800:1-32)
01 DIGIT CONVERSION
ENTER BIN NO (001–200)
Dial Digit Conversion Table Number (01–15) and enter the bin umber
(Ex.001).
01/001 DIGIT CONV.
PRESS FLEX KEY (01–18)
Dial conversion Bin No (001–200).
- Flex 1: Apply Time Type, Flex 2: Dialed Digit
- Flex 3: Unconditional Changed Digit
- Flex 4−6: Day/Night Timed Changed Digit
- Flex 7−15: LCR Time (Day/Time Zone Changed Digit)
- Flex 16: Ring mode table
- Flex 17: Apply Option
- Flex 18: ARS CO Access CO
Use the dial–pad to enter the dialed number.
Press the [Save] button to store the data entry.
Table 4.3.9.15-1 DIGIT CONVERSION TABLE ATTRIBUTES (PGM 270)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
01/001 APPLY T–TYPE
(0–2): UNCONDITIONAL
The Apply time type is to be applied when
the dialed digit is dialed.0: Unconditional,
1: Follow DNT, 2: Follow LCR
Refer to
description
Un
conditional
2
01/001 DIALED DIGIT
…………………..
The dialed digits
Max. 24 digits
3
01/001 UNCOND CHANGED
…………………..
The dialed digits are converted to this digit
stream unconditionally.
Max. 24 digits
4
01/001 DAY CHANGED
…………………..
The dialed digits are converted to this digit
stream when Apply Time type is ‘FOLLOW
DNT’ and DAY's current ring mode.
Max. 24 digits
5
01/001 NIGHT CHANGED
…………………..
The dialed digits are converted to this digit
stream when Apply Time type is ‘FOLLOW
DNT,’ and the current ring mode is NIGHT.
Max. 24 digits
6
01/001 TIMED CHANGED
…………………..
The dialed digits are converted to this digit
stream when Apply Time type is ‘FOLLOW
DNT,’ and the current ring mode is TIMED.
Max. 24 digits
