4.4.7.1 ISDN Attributes - PGM 200
Selecting ISDN Attributes will display the ISDN Attributes data entry page. Click the [Save] button after
changing Value.
Figure 4.4.7.1-1 ISDN Attributes
ISDN attributes define several characteristics of the ISDN interface. ISDN call cost services (Advice of
Charge), CLI modification, voice encoding, and other characteristics of the interface are defined. Refer to the
following table.
Table 4.4.7.1-1 ISDN ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
CO ATD Code
When the system is set to send the station number with ISDN CLIP
or COLP, either the station number or this ATD code will be sent
based on the Common Attributes section, EXT, or ATD assignment.
Max.2
Digits
CLI Print To
Serial
The ISDN Calling Line Id may be included in call records. Refer to
the SMDR Attributes section.
OFF/
ON
OFF
Display DID
Information
Display DID digit information on LCD and printed it to the serial port.
OFF/
ON
OFF
Print
Destination in
CLI Print
If this is set to ON, the following destination number is provided with
ring Information.
Station Number, Station Group, CCR, Net station, Conference room
OFF/
ON
OFF
