4.3.9.7 Flexible DID Conversion Table – PGM 231
When the received DID digits are converted as in PGM 230, the resulting 4 digit number may be used as an
index to the Flexible DID Conversion Table. The Flexible DID Table index is used when DID Line is assigned a
Conversion type 2; refer to PGM 145 Flex button 2. Based on the index from PGM 230 and the system mode
(Day, Night, or Timed), a destination for the DID call was determined. The destination can be a VSF AA
Announcement with CCR assigned, allowing further routing of the call, or can route using the ICLID routing
tables.
PROCEDURE:
FLEX DID CONV TABLE
F1:INPUT F2:INIT F3:DEL
Press the [PGM] button and dial 231.
FLEX DID CONV TBL INPUT
ENTER BIN NO (0000-9999)
Select Flex button 1~3:
- Flex button 1: Input new data, Flex button 2: Initialize Table,
Flex button 3: Delete entry
Enter the bin number (Ex.0001)
TABLE BIN 001
PRESS FLEX KEY (1-9)
Use the dial pad to enter a Table index (0000~9999).
Press the Flex button 1~9 to select the desired destination. Refer to Table
3.3.9.7-1.
Use the dial pad to enter the desired type and value for the destination.
Refer to Table 3.3.9.7-2.
Press the [Save] button to store the data entry.
Table 3.3.9.7-1 FLEXIBLE DID CONVERSION (PGM 231)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
TABLE 001 NAME
………...
Name associated with the destination.
11
characters
2
TABLE 001 DAY DEST
NONE (01-15)
Destination setting for Day Ring mode.
01-15
3
TABLE 001 NIGHT DEST
NONE (01-15)
Destination setting for Night Ring mode.
Table 3.3.9.7-2.
01-15
4
TABLE 001 TIMED_R DEST
NONE (01-15)
Destination setting for Timed Ring mode.
Table 3.3.9.7-2.
01-15
5
TABLE 001 REROUTE DEST
NONE (01-15)
Destination setting for Reroute Dest
mode. Table 3.3.9.7-2.
01-15
6
TABLE 001 USE ICLID
(1:ON/O: OFF) : OFF
A DID Conversion Table index can be
assigned to employ ICLID routing, section
3.3.8.4.
0: OFF
1: ON
OFF
