Juniper EX3300 Complete Hardware Guide

Table 3: EX3300 Switch Models
First Junos OS
Release
Direction of
Airflow
Maximum
System Power
Available for
PoE
Ports in Which PoE+
Is AvailableAccess PortsModel
11.3R1Front-to-back––24 Gigabit EthernetEX3300-24T
11.3R1Front-to-back405 WAll 24 ports24 Gigabit EthernetEX3300-24P
11.3R1Front-to-back––24 Gigabit EthernetEX3300-24T-DC
11.3R1Front-to-back––48 Gigabit EthernetEX3300-48T
11.3R1Back-to-front––48 Gigabit EthernetEX3300-48T-BF
11.3R1Front-to-back740 WAll 48 ports48 Gigabit EthernetEX3300-48P
NOTE: In rare cases, EX3300 switches running a Junos OS release prior to
Release 11.3R4 or Release 11.4R2 might experience some traffic loss or a link
failure as a result of non-user-configurable settings that are not optimized.
To resolve this issue, upgrade to one of the following Junos OS releases:
•
Junos OS Release 11.3—R4 and later
•
Junos OS Release 11.4—R2 and later
•
Junos OS Release 12.1—R1 and later
Related
Documentation
Front Panel of an EX3300 Switch on page 6•
• EX3300 Switches Hardware Overview on page 3
Chassis Physical Specifications for EX3300 Switches
The EX3300 switch chassis is a rigid sheet-metal structure that houses the hardware
components. Table 4 on page 5 summarizes the physical specifications of the EX3300
switch chassis.
Table 4: Physical Specifications of the EX3300 Switch Chassis
ValueDescription
1.75 in. (4.45 cm)Chassis height
•
17.5 in. (44.5 cm)
•
19 in. (48.2 cm) with mounting brackets attached
Chassis width
12 in. (30.5 cm)Chassis depth
5Copyright © 2015, Juniper Networks, Inc.
Chapter 1: EX3300 Switch Overview

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
