Juniper EX3300 Complete Hardware Guide

• Connecting AC Power to an EX4300 Switch
• Connecting AC Power to an EX4500 Switch
• Connecting AC Power to an EX4550 Switch
• Connecting AC Power to an EX4600 Switch
• Connecting AC Power to an EX6200 Switch
• Connecting AC Power to an EX8200 Switch
• Connecting AC Power to an EX9204 Switch
• Connecting AC Power to an EX9208 Switch
• Connecting AC Power to an EX9214 Switch
• Connecting AC Power to an XRE200 External Routing Engine
• Connecting AC Power to an OCX1100 Switch
• Connecting AC Power to a QFX3100 Director Device
• Connecting AC Power to a QFX3008-I Interconnect Device with Single-Phase Wiring
Trays
• Connecting AC Power to a QFX3008-I Interconnect Device with Three-Phase Delta Wiring
Trays
• Connecting AC Power to a QFX3008-I Interconnect Device with Three-Phase Wye Wiring
Trays
• Connecting AC Power to a QFX3500, QFX3600, or QFX3600-I Device
• Connecting AC Power to a QFX5100 Device
AC Power Disconnection Warning
This topic applies to hardware devices in the EX Series product family, which includes
EX Series switches, the EX Series Redundant Power System (RPS), and the XRE200
External Routing Engine.
This topic also applies to hardware devices in the QFX Series and to OCX1100 switches.
WARNING: Before working on the switch or near power supplies, unplug all
the power cords from an AC switch.
Waarschuwing Voordat u aan een frame of in de nabijheid van voedingen
werkt, dient u bij wisselstroom toestellen de stekker van het netsnoer uit het
stopcontact te halen.
Varoitus Kytke irti vaihtovirtalaitteiden virtajohto, ennen kuin teet mitään
asennuspohjalle tai työskentelet virtalähteiden läheisyydessä.
Copyright © 2015, Juniper Networks, Inc.182
Complete Hardware Guide for EX3300 Ethernet Switches

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
