Network Port Connector Pinout Information for an EX3300 Switch
A network port on the switch uses an RJ-45 connector to connect to a device.
The port uses an autosensing RJ-45 connector to support a 10/100/1000BASE-T
connection.
Table 15 on page 26 provides the pinout information for a network port on an EX3300
switch.
Table 15: Network Port Connector Pinout Information for EX3300 Switches
DescriptionSignalPin
Transmit/receive data pair 1
Negative Vport (in PoE models)
TRP1+1
Transmit/receive data pair 1
Negative Vport (in PoE models)
TRP1-2
Transmit/receive data pair 2
Positive Vport (in PoE models)
TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3-5
Copyright © 2015, Juniper Networks, Inc.26
Complete Hardware Guide for EX3300 Ethernet Switches
