Table 18: Management Port Connector Pinout Information for EX3300 Switches (continued)
DescriptionSignalPin
Transmit/receive data pair 4TRP4+
This pin is used only when the port is
operating at 1000 Mbps.
7
Transmit/receive data pair 4TRP4-
This pin is used only when the port is
operating at 1000 Mbps.
8
Related
Documentation
See Rear Panel of an EX3300 Switch on page 7 for port location.
Connecting a Switch to a Network for Out-of-Band Management on page 109
Pluggable Transceivers Supported on EX3300 Switches
Uplink ports on the front panel in EX3300 switches support SFP and SFP+ transceivers.
This topic describes the optical interfaces supported for those transceivers.
NOTE: We recommend that you use only optical transceivers and optical
connectors purchased from Juniper Networks with your Juniper Networks
device.
CAUTION: If you are having a problem running a Juniper Networks device
that is using a third-party optic or cable, the Juniper Networks Technical
Assistance Center (JTAC) can help you diagnose the source of the problem.
Your JTAC engineer might recommend that you check the third-party optic
or cable and potentially replace it with an equivalent Juniper Networks optic
or cable that is qualified for the device.
The Gigabit Ethernet SFP and SFP+ transceivers installed in EX3300 switches support
digital optical monitoring (DOM): you can view the diagnostic details for these transceivers
by issuing the operational mode CLI command show interfaces diagnostics optics.
NOTE: The transceivers support DOM evenif they areinstalledin uplink ports
configured as Virtual Chassis ports.
Copyright © 2015, Juniper Networks, Inc.30
Complete Hardware Guide for EX3300 Ethernet Switches
