Juniper EX3300 Complete Hardware Guide

CHAPTER 8
Planning the Virtual Chassis
•
Understanding EX3300 Virtual Chassis Hardware Configuration on page 75
•
Planning EX3300 Virtual Chassis on page 76
•
Virtual Chassis Cabling Configuration Examples for EX3300 Switches on page 76
Understanding EX3300 Virtual Chassis Hardware Configuration
Virtual Chassis is a feature in Juniper Networks EX3300 Ethernet Switches that allows
you to interconnect two or more EX3300 switches, enabling them to operate as a unified,
single, high bandwidth switch. Starting in Junos OS Release 12.2, you can interconnect a
maximum of ten EX3300 switches by using the uplink ports configured as Virtual Chassis
ports (VCPs) to form a Virtual Chassis. You can connect up to six EX3300 switches in
an EX3300 Virtual Chassis in prior Junos OS releases. By default, uplink ports 2 and 3 are
configured as VCPs.
NOTE: EX3300 switches do not have dedicated VCPs.
All EX3300 switch models support Virtual Chassis, and you can interconnect different
models, which allows you to choose among a range of possible port configurationswithin
the same Virtual Chassis.
The Virtual Chassis configuration includes a master switch and a backup switch, with all
other switches in the configuration designated as “linecard” member switches. Virtual
Chassis operation is managed through the master switch. Each switch in the Virtual
Chassis is assigned a unique member ID that is displayed on the switch LCD.
Related
Documentation
Understanding EX Series Virtual Chassis Components•
• Planning EX3300 Virtual Chassis on page 76
75Copyright © 2015, Juniper Networks, Inc.

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
