Table 5: CLI Equivalents of Terms Used in Documentation for EX3300 Switches
Additional
Information
Item in
Documentation
Value (Field as
Displayed in CLI)
Description (Field as
Displayed in CLI)
Hardware Item(Field
as Displayed in CLI)
“Chassis Physical
Specifications for
EX3300 Switches” on
page 5
Switch chassisOne of the following:
EX3300-24T
EX3300-24P
EX3300-24T-DC
EX3300-48T
EX3300-48T-BF
EX3300-48P
Chassis
Understanding Interface
Naming Conventions on
EX Series Switches
The switch does not
have actual FPCs. In
this case, FPC refers to
the switch itself.
Value of n is always 0.On EX3300 standalone
switches:
Abbreviated name of
the Flexible PIC
Concentrator (FPC)
One of the following:
EX3300-24T
EX3300-24P
EX3300-24T-DC
EX3300-48T
EX3300-48T-BF
EX3300-48P
FPC (n)
Understanding EX
Series Virtual Chassis
Components
In this case, the FPC
number refers to the
member ID assignedto
the switch.
n is a value in the range
of 0-9.
On EX3300 Virtual
Chassis:
Member ID of the
switch within the
Virtual Chassis
Understanding Interface
Naming Conventions on
EX Series Switches
The switch does not
have actual PIC
devices; see entries for
PIC 0 through PIC 1 for
the equivalent item on
the switch.
n is a value in the range
of 0–1.
Abbreviated name of
the Physical Interface
Card (PIC)
PIC (n)
“Front Panel of an
EX3300 Switch” on
page 6
Built-in network ports
on the front panel of
the switch
PIC 0One of the following:
24x 10/100/1000
BASE-T
48x 10/100/1000
BASE-T
“Front Panel of an
EX3300 Switch” on
page 6
Built-in uplink ports on
the front panel of the
switch
PIC 14x GE/XE SFP+
9Copyright © 2015, Juniper Networks, Inc.
