Table 9: Status LED on the Network Ports in EX3300 Switches
State and DescriptionLCD IndicatorLED
Indicates the speed.
The status indicators are:
•
Unlit—10 Mbps
•
Blinking—100 Mbps
•
On steadily—1000 Mbps
LED: SPDStatus
Indicates the administrative status. The status indicators are:
•
On steadily—Port is administratively enabled.
•
Off—Port is administratively disabled.
LED: ADM
Indicates the duplex mode.
The status indicators are:
•
Green—Port is set to full-duplex mode.
•
Unlit—Port is set to half-duplex mode.
LED: DPX
Indicates the PoE status.
The status indicators are:
•
On steadily—PoE is available on the port.
•
Blinking—PoE is available on the port, but no power is drawn
from the port because of one of the following:
•
No device that draws power from the port is connected
to the port.
•
A device that draws power from the port is connected to
the port, but the device is not drawing any power from
the port.
•
Unlit—PoE is not enabled on the port.
LED: POE
